plate prefabrication for wind towers

FALCON - 4-Side Plate Edge Milling Machine

LINSINGER’s latest plate edge milling machine generation PFM FALCON enables edge preparation on all 4 sides
(2 longitudinal + 2 cross sides) of a plate in one clamping. Our proven “LINSINGER Thick Chip Milling Technology” ensures
high feed and output rates at lowest possible tooling cost.
Due to the gantry milling concept and the magnetic clamping units, highest flexibility is given and even complex
plate shapes such as trapezoidal and curved plates (e.g. for the vessel and wind tower industry) can be processed.
For non-magnetic and complex materials such as Stainless Steel, High alloyed steels, Duplex and Super-Duplex
grades, special clamping tables are available. Optional minimum quantity lubricant spray nozzles ensure economic
machining even of these materials.
The machine covers easily plates with wall thicknesses from 10mm up to 200mm (0,4 – 8”). The high-power reserves of the
machine ensure maximum torque of 6000 Nm and high feed rates even when heavy plates are milled. Various profile types
(N/V/X/Y/J) can be realized. The proven copying function of the milling unit ensures a constant web-flow along the plate edge,
even on heavily bent plates of high thickness.

Features

High feed rates and low tool cost with “Linsinger Thick Chip Milling Technology”

All 4 sides of a plate are machined in one clamping

Automatic machine setup for each plate dimension

Different profiles on each edge possible

Precise and fast welded seam preparation

Various kinds of profiles available (V/X/Y/J…)

Automatic tool changer function available

Milling of various plate geometries (trapezodial, curved) possible

technical data

cycle time: 20 min

12,000 x 3,000 mm
(40ft x 10ft)
t = 50 mm (2 “)

carbon steel

AVAILABLE OPTIONS

Milling of Stainless Steel

Alternative clamping solutions for Stainless Steel

Surface milling function

Milling of curved & trapezodial plates

reliable plate edge milling machine pfm

Fräsmaschine PFM
FOR LARGE PIPES, SIMULTANEOUS PREPARATION OF WELDED EDGES ON BOTH LONGITUDINAL SIDES

Type PFM 90/600

Worldwide fastest 4-side milling machine

Developed for rectangular, trapezoidal and conical plates

Perfect welding edge preparation for heavy plates

Precise weld preparation on all 4 sides with 2 milling stations

Reduced downtimes due to automatic tool changing device

The proven height copying function ensures constant web flow along the plate edge

Features

All 4 sides of a plate are machined in one clamping

Automatic machine setup for each plate dimension

Heavy rigid machine design

Automatic tool changing

TECHNICAL DATA

working range:

max. 30,000 x 5,000 x 160 mm

connected power: 480 kW

total weight: 404 t

EXAMPLES OF POSSIBLE EGDE FORMS FOR PLATE EDGE MILLING MACHINES PFM LL

HIGHLIGHTS

High productivity through simultaneous milling on both longitudinal sides

Weld seam preparation with maximum accuracy

Vertical copying milling units with profile milling tools
